4G-AX56

Product Overview
Cat.6 300Mbps Dual-Band WiFi 6 AX1800 LTE Router,Captive portal,AiProtection Classic network security,Parental controls
  • New-generation WiFi 6 – Enjoy ultrafast speeds up to 1800 Mbps with the latest WiFi 6 (802.11ax) standard and 80MHz bandwidth for better capacity and efficiency.
  • Easy WiFi Portal – Easy share your network with click-through Free WiFi portal; grow your business with sign-on Captive Portal to set up customer or visitor WiFi within steps.
  • Ultimate 4G Speed – 4G LTE Category 6 technology lets you enjoy 7X faster speeds than 3G mobile broadband.
  • Protection for Your Home Network – lifetime free AiProtection, powered by Trend Micro™, blocks internet security threats for all your connected smart devices.

  • Free shipping on orders above £150. Delivery time: 2-4 Working Days

£209.99
Add to Wish List

Add to Wish List
209.99
ASUS
Free Shipping
Free Shipping Free shipping on orders above £150
Safe and Secure Payment
Safe and reliable payment Secure encryption for all transactions
Free Shipping
Free Shipping Free shipping on orders above £150
Safe and reliable payment Secure encryption for all transactions
Safe and Reliable Payment Secure encryption for all transactions

Get Your Home Ready for WiFi 6 (802.11ax)

The growing number of connected personal and IoT devices has led to an overall increase in network density that is pushing the limits of the current WiFi standard. The latest WiFi 6 standard provides future-proof technologies, higher network efficiency, faster WiFi speeds, greater coverage and improved battery life for connected devices, providing a significantly better networking experience for users.
*It requires WiFi 6-compatible devices to enjoy the benefits brought by WiFi 6 WiFi standard.

Next-Gen WiFi Speed

ASUS 4G-AX56 is a 2x2 dual-band WiFi 6 LTE Modem Router that provides 80MHz bandwidth and 1024-QAM for dramatically faster wireless connections. With a total networking speed of about 1800Mbps — 574Mbps on the 2.4GHz band and 1201Mbps on the 5GHz band — 4G-AX56 is 1.5X faster than WiFi 5 2x2 dual-band LTE Modem Router1.

Built for Multi-device Households

With a revolutionary combination of OFDMA and MU-MIMO technology, WiFi 6 technology provides up to 4X greater network capacity and efficiency in traffic-dense environments. Previous-generation WiFi 5 can only handle one device at a time on each network channel, which is an inefficient use of available bandwidth. OFDMA support in the WiFi 6 standard divides each channel into small sub-channels, allowing signals from multiple devices* to be bundled together and transmitted simultaneously, reducing latency for a smoother, more responsive WiFi experience.

Better Battery Life for Your Devices

Target Wake Time (TWT) allows 4G-AX56 to schedule designated intervals for devices to transmit data. This allows them to sleep when there is no need to wait for a router signal, reducing power consumption by up to 7X for significantly improved battery life*.

WiFi that Goes Farther

With the latest WiF6 WiFi standard featuring OFDMA technology, 4G-AX56 provides increased WiFi signal range and better coverage by dividing each channel into smaller sub-channels. These sub-channels have a smaller bandwidth that enables them to travel up to 80% farther2, resulting in a better WiFi connection throughout your home*.

The true wireless network where you need it

4G-AX56 offers unparalleled convenience of use. Long-term tests guarantee wide compatibility and reliability. Just insert a Nano SIM card and enjoy the convenience of 3G/4G mobile broadband connection anywhere for home and SOHO with less mess of cable.

Super-fast mobile broadband

4G-AX56 features the latest LTE Category 6 mobile broadband, which combines two cellular bands to give you internet download speeds of up to 300Mbps — 2X faster than LTE Category 4, and 7X faster than 3G (HSPA+) — so you can share even the biggest files and stream 4K UHD video with ease.

Protection for your Home Network

All your family members, young or old, are exposed to the dangers of internet every single moment they're online. 4G-AX56 includes AiProtection powered by Trend Micro™ with automatic, regularly updated security signatures to protect your devices and personal data from internet threats.

Connectivity Options

4G-AX56 has one Gigabit WAN port and four Gigabit LAN ports. Smart TV, game consoles, NAS storage devices, backup internet and more can now have their own dedicated ports, making 4G-AX56 your solid digital home hub.

Network Standard

IEEE 802.11a
IEEE 802.11b
IEEE 802.11g
WiFi 4 (802.11n)
WiFi 5 (802.11ac)
WiFi 6 (802.11ax)
IPv4
IPv6

Product Segment

AX1800 ultimate AX performance

Data Rate

802.11a : up to 54 Mbps
802.11b : up to 11 Mbps
802.11g : up to 54 Mbps
WiFi 6 (802.11ax) (2.4GHz) : up to 574 Mbps
WiFi 6 (802.11ax) (5GHz) : up to 1201 Mbps

Connectivity Technology

LTE: Downlink 300 Mbps / Uplink 50 Mbps HSPA+: Downlink 42 Mbps / Uplink 11 Mbps 4G FDD-LTE: 1 /3 /5 /7 /8 /20 /28 4G TDD-LTE: 38 /40 /41 3G UMTS: 1 /3 /5 /8

Antenna

WiFi: 2 x external fixed antenna LTE: 1 x external fixed antenna, 1 x internal antenna

Memory

128 MB Flash 512 MB RAM

Operating Frequency

2.4 GHz / 5 GHz

Ports

1 x Gigabit WAN port, 4 x Gigabit LAN ports, 1 x Nano SIM tray slot

Button

Power, Reset, WPS

LED Indicator

Power x 1 WiFi x 2 WAN x 1 Mobile WAN connection x 1 Mobile WAN signal x 3

Package content

4G-AX56 Quick Start Guide Warranty Card RJ45 Cable Power Adapter

Product Weight (g)

513

Router APP

ASUS Router APP

Alexa

Support Alexa skill

AiProtection

AiProtection Classic
Router Security Assessment
Malicious site blocking

Parental Control

Parental Control
Parental Control Customized Internet schedule

Traffic Control

Bandwidth limiter
Traditional QoS
Real-time traffic monitor
Wired Traffic Monitor

Wireless

IPv6
MU-MIMO
Wi-Fi Encryption : WPA/WAP2-Enterprise,WPA/WPA2-Personal,WPA2-Enterprise,WPA2-Personal,WPA2/WPA3-Personal,WPA3-Persona
UTF-8 SSID
Guest Network
Guest Network Connection time limit
WPS
Wi-Fi MAC address filter
Wireless scheduler
Airtime fairness
Universal beamforming
Explicit beamforming

WAN

Internet connection Type : Mobile WAN, Ethernet WAN
Dual WAN
Port forwarding
DMZ
DDNS
NAT Passthrough : PPTP, L2TP, IPSec, RTSP, H.323, SIP Passthrough, PPPoE relay

LAN

DHCP Server
IGMP snooping
IPTV
Manually assign IP address
Maximum manually assign IP address rule : 64

VPN

VPN Client L2TP
VPN Client OVPN
VPN Client PPTP
VPN Server OVPN
VPN Server PPTP

Administration

Operating mode : Modem Router,Access Point
Operating system
Firewall
Maximum Firewall keyword filter : 64
Maximum Firewall network service filter : 32
Maximum Firewall URL filter : 64
Wake on LAN (WOL)
Configuration backup and restore
SSH
Diagnosis tools
Feedback system
System log

Network Standard

IEEE 802.11a
IEEE 802.11b
IEEE 802.11g
WiFi 4 (802.11n)
WiFi 5 (802.11ac)
WiFi 6 (802.11ax)
IPv4
IPv6

Product Segment

AX1800 ultimate AX performance

Data Rate

802.11a : up to 54 Mbps
802.11b : up to 11 Mbps
802.11g : up to 54 Mbps
WiFi 6 (802.11ax) (2.4GHz) : up to 574 Mbps
WiFi 6 (802.11ax) (5GHz) : up to 1201 Mbps

Connectivity Technology

LTE: Downlink 300 Mbps / Uplink 50 Mbps HSPA+: Downlink 42 Mbps / Uplink 11 Mbps 4G FDD-LTE: 1 /3 /5 /7 /8 /20 /28 4G TDD-LTE: 38 /40 /41 3G UMTS: 1 /3 /5 /8

Antenna

WiFi: 2 x external fixed antenna LTE: 1 x external fixed antenna, 1 x internal antenna

Memory

128 MB Flash 512 MB RAM

Operating Frequency

2.4 GHz / 5 GHz

Ports

1 x Gigabit WAN port, 4 x Gigabit LAN ports, 1 x Nano SIM tray slot

Button

Power, Reset, WPS

LED Indicator

Power x 1 WiFi x 2 WAN x 1 Mobile WAN connection x 1 Mobile WAN signal x 3

Package content

4G-AX56 Quick Start Guide Warranty Card RJ45 Cable Power Adapter

Product Weight (g)

513

Router APP

ASUS Router APP

Alexa

Support Alexa skill

AiProtection

AiProtection Classic
Router Security Assessment
Malicious site blocking

Parental Control

Parental Control
Parental Control Customized Internet schedule

Traffic Control

Bandwidth limiter
Traditional QoS
Real-time traffic monitor
Wired Traffic Monitor

Wireless

IPv6
MU-MIMO
Wi-Fi Encryption : WPA/WAP2-Enterprise,WPA/WPA2-Personal,WPA2-Enterprise,WPA2-Personal,WPA2/WPA3-Personal,WPA3-Persona
UTF-8 SSID
Guest Network
Guest Network Connection time limit
WPS
Wi-Fi MAC address filter
Wireless scheduler
Airtime fairness
Universal beamforming
Explicit beamforming

WAN

Internet connection Type : Mobile WAN, Ethernet WAN
Dual WAN
Port forwarding
DMZ
DDNS
NAT Passthrough : PPTP, L2TP, IPSec, RTSP, H.323, SIP Passthrough, PPPoE relay

LAN

DHCP Server
IGMP snooping
IPTV
Manually assign IP address
Maximum manually assign IP address rule : 64

VPN

VPN Client L2TP
VPN Client OVPN
VPN Client PPTP
VPN Server OVPN
VPN Server PPTP

Administration

Operating mode : Modem Router,Access Point
Operating system
Firewall
Maximum Firewall keyword filter : 64
Maximum Firewall network service filter : 32
Maximum Firewall URL filter : 64
Wake on LAN (WOL)
Configuration backup and restore
SSH
Diagnosis tools
Feedback system
System log
